860

6 products

Description

Application: For longitudinal cutting of softwood and hardwood, dry.

Machine: For single and double spindle multi-rip machines with horizontal or vertical spindles, sliding table saws, table saws, etc.

Technical information: With flat or triple chip flat grinded carbide teeth (HW). With large gullets for high chip evacuation.

D B b d Z α NL/TK Machine Ref.
250 3,2 2,2 30 20 25º NL30 860.250.020.30
300 3,2 2,2 30 24 25º NL30 860.300.024.30
3,4 2,2 80 28 20º Raimann 860.300.128.80 #
350 3,5 2,5 30 28 25º NL30 860.350.028.30
3,6 2,4 80 30 20º Raimann 860.350.030.80 ##
400 4,0 2,8 30 32 25º NL30 860.400.032.30


Glue line saw blades

D B b d Z Machine Ref.
300 4,0 2,8 80 28 Raimann 860.300.228.80 ###
2,8 1,8 80 48 Raimann 860.300.248.80 ###
4,0 2,8 80 48 Raimann 860.300.148.80 ###
860
