861

12 products

Description

Application: For longitudinal and cross cutting of softwood and hardwood, dry.

Machine: For single and double spindle multi-rip machines with horizontal or vertical spindles, sliding table saws, table saws, etc.

Technical information: With alternate top bevel grinded carbide teeth (HW). With large gullets for high chip evacuation.

D B b d Z NL/TK KN Machine Ref.
250 3,2 2,2 30 24 NL30 861.250.024.30
3,2 2,2 30 36 NL30 861.250.036.30
300 2,7 1,8 70 28 2/21x6 861.300.128.70
3,2 2,2 30 28 NL30 861.300.028.30
3,2 2,2 30 36 NL30 861.300.036.30
3,2 2,2 70 36 2/21x6 861.300.036.70
3,2 2,2 80 36 Raimman 861.300.036.80
350 3,5 2,5 30 36 NL30 861.350.036.30
400 3,5 2,5 30 28 NL30 861.400.028.30
3,5 2,5 30 36 NL30 861.400.036.30
450 4,0 2,8 30 40 NL30 861.450.040.30
500 4,4 2,8 30 44 NL30 861.500.044.30
4,4 2,8 30 60 861.500.060.30
4,4 2,8 35 60 NL35 861.500.060.35
550 4,4 3,0 30 60 NL30 861.550.060.30
600 6,0 3,9 30 60 NL30 861.600.060.30
650 5,6 3,8 30 96 4/8,5/90+2/14/400 Hundegger 861.650.096.30
720 6,0 4,4 30 72 4/8,5/90+2/14/400 Hundegger 861.720.072.30
735 6,0 4,4 30 72 4/8,5/90+2/14/400 Hundegger 861.735.072.30
760 6,0 4,4 30 72 4/8,5/90+2/14/400 Hundegger 861.760.072.30
800 6,0 4,4 30 80 4/8,5/90+2/14/400 Hundegger 861.800.080.30
1000 4,8 3,6 40 80 1/12,5/90 Palax 861.999.080.40
861
