Description
Application: For cutting of high density coating wood based materials (laminated boards, HPL, etc.).
Machine: For sliding table saw machines, table saws, vertical panel sizing machines, etc.
Technical information: With triple chip flat grinded carbide teeth (HW). Saw blade produced with long life tips for maximum wear resistance and extra-long lifetime. For finish cut quality with scoring saw blade. For vertical panel sizing machines it is recommended to work with negative hook angle.
| D | B | b | d | Z | NL/TK | Ref. |
|---|---|---|---|---|---|---|
| 250 | 3,2 | 2,2 | 30 | 80 TFN | NL30 | 866.250.280.30 |
| 3,2 | 2,2 | 30 | 80 TF | NL30 | 866.250.380.30 | |
| 300 | 3,2 | 2,2 | 30 | 96 TFN | NL30 | 866.300.196.30 |
| 3,2 | 2,2 | 30 | 96 TF | NL30 | 866.300.396.30 | |
| 350 | 3,5 | 2,5 | 30 | 108 TF | NL30 | 866.350.308.30 |
