Scoring Saw Blades

46 products

Saw Blade Application

872

872

 871

871

 853

853

Description

Application: For scoring groove on coated woodbased materials. For finish cut on bottom of first board.

Machine: For panel sizing machines and sliding table saws with scoring saw.

Technical information: With conical alternate grinded carbide teeth (HW). Saw blade produced with long life tips for maximum wear resistance and extra-long lifetime. The cutting width from scoring saw blade must be the same as that of the main saw blade. To work with the feed. Recommended incision depth 1,0-2,0 mm.

D Kerf B b d Z Angle Machine Ref
80 3,1–4,3 2,2 20 12 0° SCM 871.080.012.20
100 3,1–4,3 2,2 20 20 0° Schelling 871.100.020.20
3,1–4,3 2,2 22 20 0° 871.100.020.22
115 4,1–5,1 3,0 45 24 -8° SCM 871.115.024.45
120 3,1–4,3 2,2 20 24 0° Robland 871.120.024.20
3,1–4,3 2,2 22 24 0° Inmes 871.120.024.22
125 3,1–4,3 2,2 20 24 0° 2/8/42 Panhans, Frama 871.125.024.20
3,1–4,3 2,2 22 24 0° Panhans 871.125.024.22
4,4–5,6 3,2 20 24 0° Gabbiani, SCM 871.125.124.20
4,4–5,6 3,2 45 24 0° Giben, Homag 871.125.024.45
150 4,4–5,6 3,2 20 24 8° Paoloni, Fimal, Schelling 871.150.024.20
4,4–5,6 3,2 30 24 8° SCM 871.150.024.30
4,4–5,6 3,2 30 36 8° Felder 871.150.036.30
4,4–5,6 3,2 45 24 8° Holzma, Homag, Egurko 871.150.024.45
4,45–5,45 3,2 45 28 8° Homag Sawteq 871.150.028.45
160 4,4-5,6 3,2 45 36 8° NL45 Giben 871.160.036.45
160 4,4-5,6 3,2 55 36 8° NL55 Casadei, Gabbiani, SCM, Macmazza 871.160.136.55
160 4,4-5,6 3,2 65 36 8º 2/9/80 Nimac, Cehisa 871.160.036.65
180 4,4-5,6 3,0 20 28 8° 2/9/60 Anthon 871.180.028.20
180 4,4-5,6 3,0 30 28 8° NL30 Panhans 871.180.028.30
180 4,4-5,6 3,2 30 30 8º NL30 HolzHer 871.180.130.30
180 4,4-5,6 3,2 45 36 8° NL45 Holzma, Giben 871.180.136.45
180 4,4-5,6 3,2 50 42 8° 3/13/80+4/13/80 Giben 871.180.042.50
180 4,45-5,6 3,2 45 36 8° Homag Sawteq 871.180.436.45
180 4,8-5,8 3,5 20 36 8° 2/9/60 Anthon 871.180.036.20
180 4,85-5,8 3,5 45 36 8° Holzma, Homag Sawteq 871.180.036.45
200 4,4-5,6 3,2 20 36 8° 2/11/66 +2/9/110 Schelling 871.200.036.20
200 4,4-5,6 3,2 30 36 8° NL30 Scheer, Panhans 871.200.036.30
200 4,4-5,6 3,2 45 36 8° Holzma, Homag, Egurko 871.200.436.45
200 4,4-,5,6 3,2 50 36 8º 2/7/80 Masterwood, Scheer 871.200.136.50
200 4,4-5,6 3,2 50 42 8° 3/13/80 Giben Smart 65 871.200.042.50
200 4,4-5,6 3,2 65 36 8° 2/9/100+2/9/110+2/11/110 Biesse, Selco 871.200.136.65
200 4,4-5,6 3,2 80 36 8° NL80 Gabbiani 871.200.136.80
200 4,45-5,6 3,2 45 36 8º Homag Sawteq 871.200.736.45
200 4,8-5,8 3,5 45 36 8° Holzma, Homag 871.200.036.45
200 4,8-5,8 3,5 65 36 8° NL65 Selco 871.200.036.65
200 5,5-6,7 3,4 20 36 8° 2/11/66 +2/9/110 Schelling 871.200.136.20
200 5,8-6,8 3,5 45 36 8° Holzma, Homag 871.200.236.45
200 6,2-7,2 4,0 45 36 8° Holzma, Homag 871.200.336.45
215 4,4-5,6 3,2 50 42 8° 3/15/80+2/7/80 Giben 871.215.042.50
215 4,8-5,8 3,5 50 42 8° 3/7/80+3/15/80 Giben 871.215.142.50
220 6,5-7,4 4,5 20 36 8° 2/9/110+2/11/66 Schelling 871.220.036.20
250 4,4-5,6 3,2 50 42 8° 3/13/80 Giben 2 871.250.042.50
280 4,55 3,5 45 84 W 15º Holzma HPP250 Postforming 871.280.084.45
300 4,4-5,6 3,2 30 36 8° 2/13/94+2/9/100+2/9/110+2/11/73 Schelling 871.300.036.30
300 4,4-5,6 3,2 30 48 8° 2/13/94+2/9/100+2/9/110+2/11/73 Schelling 871.300.048.30
300 4,4-5,6 3,2 50 48 8° 3/15/80 Giben 871.300.048.50
300 4,4-5,6 3,2 65 48 8° NL65 Selco EB 871.300.048.65
300 4,4-5,6 3,2 80 48 KW 8° NL80 SCM 871.300.048.80
300 4,55 3,5 80 72 WE 15° NL80 Gabbiani Postforming 871.300.072.80
340 5,0 3,5 45 108 WE 15º 3/14/65 Holzma Postforming 871.340.108.45
Scoring Saw Blades
